- The TF7700HDPVR achieved 'Good' and 'Very Good' from these
important German Digital Receiver Magazines.
- TF7700HDPVR achieved 'Very Good' from 'Digital
Fernsehen'.
|
|
 |
- Fully DVB-S / DVB-S2 (H.264) HD compliant
- With 2 tuners
- Time shift supported
- Dual Recording supported
- XviD codec embedded
- USB memory supported
- 5000 TV & radio services programmable
- Multilingual audio support
- Multilingual menu text support
- Favorite service list editing
- Electronic Program Guide (EPG) for on screen service
information
- Subtitle supported
- Parental lock facility by service and program event
- Firmware update via LAN port
| Transport Stream A/V Decoding |
|
| Aspect Ratio |
4:3, 16:9 |
| Video Resolution |
576i, 576p, 720p,1080i |
| A/V & Data In/Out |
|
| TV Scart |
Video CVBS/RGB/YUV output, Audio L/R output |
| VCR-Scart |
Video CVBS output, Audio L/R output |
|
Video CVBS output, Audio L/R input for bypass |
| RCA A/V |
Video CVBS output |
|
Audio L/R output |
| HDMI |
HD Video/Audio Output |
| Component |
YPbPr output |
| S-VIDEO |
Video S-VIDEO output |
| S/PDIF |
Digital audio or Dolby AC3 bitstream output |
| LAN |
10/100 Mbps Ethernet |
| RS-232C |
9 pin D-sub type |
|
Transfer rate : max. 115.2Kbps |
| Front Panel |
|
| Keys |
5 Keys(VOL -/+, STANDBY, CH -/+) |
| USB |
USB 2.0 Host |
| RCU |
48 Keys
|
|
|
| Power Supply |
|
| Input Voltage |
95 250 VAC, 50/60Hz
|
|
|
| Type |
SMPS
|
|
|
| Power Consumption |
Running: Max. 60W, Standby: 9W
|
|
|
| Physical Specifications |
|
| Size(WxHxD) |
430 x 60 x 265 mm
|
|
|
| Weight(Net) |
3.8 kg
|
| | |
 | |
